Silver 8ft X 12ft Chain Link Construction Fence ASTM A392-06 Standar

Brand Name : top fence

Model Number : chain link wire temporary construction fence panels

Certification : ISO

Place of Origin : china

MOQ : 1 x 40hc container 200 set -400 set

Price : 29.88 -46.88usd

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 10000 pcs per year

Delivery Time : 14 days

Packaging Details : metal pallet wrapped with plastic

Materials : Pre-galvanized pipes 14 microns ,28 microns ,42 microns

Panels size : 6ft x 10ft,12ft ,14ft 8ft x 12ft etc

Color : silver

Steel pipes : 1-3/8 inch pipes ,1-1/4 inch thick 1.6mm

Mesh opening : 60mm x 60mm ,57mm x 57mm or 2-3/8 inch x 2-3/8 inch

Diameter : 2.5mm ,2.7mm,3.00mm

Special note foot : all foot and punched middle pipes with holes then full welded

Foot types : 920 mm x 413mm x 200mm or customized

Panels brace types : horizontal ,vertical ,cross brace

Contact Now

**Temporary Construction Fence ASTM A392-06 Standard 8ft x 12ft 1½”(38mm) x 1.6mm wall thcik mesh 60mm*60mm**

Temporary chain link fence is one types of temporay fence incoperated with advantage of portable and removable as well easy to installation steel block with a dimension 36” length x 30” width x 8” Height /914mmx762mmx203mm stand in stabilities ,all Horizontal pipes are ARC design then fully welding temporary chain link construction fence available 6'x12' ,8'x12' and so on

Temporary Chain Link Fence /Construction Fence Panels Spec
Tubing	1¼”(32mm) 1⅜”(35mm) 1½”(38mm) 1⅗”(40mm) 1⅝”(42mm) 1⅞”(48mm)and so on
Thickness of Tubing	16GA/ 1.6mm thick as a standard or customized owned size
Chain mesh aperture	2”x2/”(50mm x 50mm) 2¼”x2¼”(57mmx57mm) 2⅜x2⅜(60mmx60mm) 2½”x2½” (63mmx63mm)
Height	4ft/1220mm 6ft/1820mm 8ft/2420mm
Width	12ft /3650mm was wide acceptance by market also 8ft 9ft 10ft 14ft
Panels Size	6ft x 12ft ,8ft x 12ft, 4ft x 12ft and so on
Diameter /Gauge	10ga/3.2mm ,10.5ga/3.00mm ,11ga/2.90mm,11.5ga/2.75mm,12ga /2.60mm 12.5ga/2.5mm 13ga/2.3m
Base Optional 1	36” length x 30” width x 8” Height /914mmx762mmx203mm
Base Optional 2	36” length x 16” width x 8” Height /914mmx406mmx203mm
Base Optional 3	30” length x 18” width x 8” Height /762mm x460mm x203mm
Standard	ASTM A392-06
Steel	Galvanized Steel Construction
Finish	Corrosion-Resistant Zinc Coating
Transport Packing	Metal pallet Wrapped with Plastic
HDG zinc thickness	14 microns 100gram/SQM 28 microns 200 gram/SQM 42 microns 300 gram/SQM and 84 microns 600 gram/SQM

3. Chain link fence features:

1).It can quickly and easily be installed, without the need to disturb the surface area by digging holes or laying foundations.

2).Weather resistant and durable, and will last much longer; The temporary fences are light and easy to handle, while being strong and robust at the same time;

3).The feet are removable which makes transportation and storage much easier and more efficient

4).Easy to Erect - four metres a minute

Light and easy to handle

Create a gate at any point on the perimeter

Economical temp fence - can be used time after time

Delivered accompanied by fork lift for easy distribution

Constructed from heavy gauge galvanized tube and welded mesh infill

4.Construction chain link fence productive process:

Pre hot dip galvanized wire drawing--- cut wire and pipes ---wire weave---cut the corners of the mesh---Pre hot dip galvanized pipes welded—polish the welds—paint anti-rust epoxy—spray sliver powder coat on each welds—stacking—packaging

Silver 8ft X 12ft Chain Link Construction Fence ASTM A392-06 Standar
